Product Details
The heavy duty forklift 12 ton is the regular CPCD120 counterbalance model we use when a heavy load can still be handled in the normal way with forks. At this capacity, we prefer to start with the actual job instead of adding options to the specification before we know what the truck will be asked to do.
A buyer may tell us that the load is twelve tons, but that only gives us one part of the picture. A compact machine component, a long fabricated frame and a large block can be close in weight while behaving very differently once they are picked up.
For that reason, our discussion normally moves quickly from the forklift itself to the load and the working route. Those two points tell us much more about the requirement than a long list of accessories.

Product Parameters
| Item | Specification |
|---|---|
| Model | CPCD120 |
| Rated Capacity | 12,000 kg |
| Standard Engine | Yuchai YC6B125-T21-II |
| Rated Power | 92 kW |
| Transmission | 2 Forward / 2 Reverse |
| Mast | Duplex |
| Tire Layout | Front 4 / Rear 2 |
A 12-Ton Load Is Not Enough Information
The rated condition of this CPCD120 uses a 600 mm load center. That figure matters once the cargo becomes longer, deeper or uneven in shape.
A load whose center of gravity sits farther forward does not put the truck in the same working condition as a compact load of the same weight. We therefore do not treat "12 tons" as a complete specification by itself.
For the heavy duty forklift 12 ton, we would rather see the cargo dimensions before finalizing a proposal. A drawing is useful when available, but length, width, height and the intended pickup direction are already a good start. If the load has an unusual support point or the weight is clearly concentrated toward one end, that should also be mentioned.
Sometimes this information changes very little. Sometimes it changes the way the requirement has to be considered. It is better to find that out while the truck is still being specified.
What Happens After the Forks Pick It Up?
We also ask where the load starts and where it has to go.
Lifting something from a trailer and setting it down a short distance away is one type of job. Carrying the same load repeatedly across an outdoor yard is another. The weight has not changed, but the truck is being used differently.
Travel distance, ground condition and slopes are useful details here. So is handling frequency. If the machine will make the same loaded trip many times during a shift, we want to know that before the heavy duty forklift 12 ton is put into production.
Turning space can matter as well, particularly when the load itself is long. A route that is comfortable for an empty forklift may feel very different once a long piece is sitting on the forks.
We do not need a formal site survey for every enquiry. A few photos of the working area, together with a simple description of the route, are often enough to make the discussion much more useful.
FAQ
Q1. Can An Operator Presence System Be Added?
Yes. OPS is available as an optional item for this model.
Q2. Can The Forklift Be Supplied With Solid Tires?
Yes. Solid tires can be specified when they are required for the order.
Q3. Is A Reversing Camera Available?
Yes. A reversing camera can be added to the final configuration.
